Kala ARKANE 1650

ARKANE 1650 is a flatbed laminator for signage and graphics teams that need reliable, high-quality finishing.

Key benefits

  • Delivers professional finishing for mounting and lamination workflows
  • Supports bubble-free application and consistent finishing quality
  • A practical fit for signage teams handling premium graphics and display work
  • Hot and cold lamination, with rollers heating from 30°C to 140°C
  • Variable speed from 0.3 to 6.5 m a minute to suit each job
  • Mounts boards up to 50 mm thick across a 1,710 mm working width

Features

  • Arkane 1650 D: Same as standard Arkane 1650 but includes dual heating top and bottom, for media technical works with media requiring heat to reactivate adhesive backing.
  • Arkane 1650 D Features Dual Heating: Features rollers that heat from 30 °C to 140 °C, allowing precise hot and cold lamination, encapsulation, single-side lamination, and mounting for professional results. The Arkane 1650 D features dual heating for technical works with media that require heat to reactivate adhesive backing.
  • Speeds From 03 To 65 M Minute: Adjustable speeds from 0.3 to 6.5 m / minute to support optional workflow enhancements like inline slitting, LED lighting, and remote control for maximum efficiency.

Media Handling

  • Inline Cutting: Includes two indexable cutting heads for trimming laminated documents or film before lamination.
  • Max Working Width: 1710 mm (67″)
  • Roller Heating: 30°- 140°C
  • Maximum Media Thickness: 50 mm (2″) (film width up to 1650 mm/65″, roll diameter up to 119 mm/4.7″, heating time to 40°C ~7 min)

Workflow

  • Power Supply: 1800 W – 230 V 8A – 50-60Hz (Arkane D: 3400 W – 230V 16A – 50-60Hz)
  • Gas Strut: Provides additional safety by slowing the descent of the table.
  • Graduated Autolocking Shaft: Facilitates loading of rolls, usable for storage, and compatible with AppliKator and KalaXY systems.
  • Led Lighting: Ideal for monitoring ongoing work and illuminating the finishing area.
  • Magnetic Antistatic Cord: Essential for discharging static electricity generated by certain materials.
  • Remote Control: Recommended for applications where operators need to work at a distance from the machine.

Physical

  • Dimensions: 206 x 82 x 153 cm
  • Weight: 210 kg
