Kala GinkoLam

GinkoLam is a flatbed laminator for signage and graphics teams that need reliable, high-quality finishing.
Key benefits
- Delivers professional finishing for mounting and lamination workflows
- Supports bubble-free application and consistent finishing quality
- A practical fit for signage teams handling premium graphics and display work
- Mounts boards up to 45 mm thick for rigid display work
- Takes film up to 63 inches wide across a 65-inch working width
- Heated roller up to 60°C for films that need a little warmth
Features
- Shafts Delivered With The Machine: 4 self-blocking shafts included; the brake tension on each shaft is adjustable.
- Footswitch: The rollers can be driven by a footswitch to keep your hands free while feeding the media into the machine and to stop the feed instantly without using the control panel.
- Linear Counter: Visualises the advance of your work. Useful for roll-to-roll operations and to see the remaining material left on the roll of media.
- Control Panel: All functions of the GinkoLam are managed by this easy-to-use control panel.
- Document Guide: Inserting the media flat through the roller without crossing the laser barrier is easy with the removable feeding guide.
- Warranty: 1 year
Print Performance
- Cutting / Processing Speed: 1 – 5 m/mn (3 – 16 ft/mn)
Media Handling
- Max Working Width: 45 mm (1.7″) (film width up to 160 mm/63″, roller diameter 130 mm/52″)
Workflow
- Power Supply: 110V – 230V, 50/60Hz 2.5kW
- Graduated Autolocking Shaft: Graduated for a quick and easy alignment of the print media and laminating film on the machine.
- Rewinder: A rewinder is integrated at the back of the laminator for a one-person operation, without the risk of damaging the laminated prints.
- Safety: Two easily accessible emergency buttons and two laser cells, located in front of the rollers, stop the roller motion immediately when engaged. The machine is reactivated by pressing the reset button after correcting the operation default.
Physical
- Dimensions: 202 x 58 x 138 mm
- Weight: 150 kg
- Table Height: 101 cm (39.8″)
Frequently asked questions
Can I see it running before I buy?
Talk to us and we'll organise a demonstration on the machine you're considering, at our Demonstration Centre in Woking.
About the Demonstration Centre →
Who installs and looks after it?
We supply, install and support every machine we sell. A Service Plan keeps it running: manufacturer-trained engineers, genuine manufacturer parts and one number to call.
Can I spread the cost?
Most customers spread the cost over 36 or 60 months. We work with a finance provider, or a broker of your choice — speak to us and we will help you find the right option for your business.
Do you pass on manufacturer offers?
Yes. Every cashback and promotional offer on printers is passed from our partners to you.
Where do you work?
We supply and support businesses across London and South England.
