HP DesignJet T850 36-in Printer
HP DesignJetT850 36″ Printer is a CAD and technical printer for architects, construction teams, engineers that need accurate, dependable large-format output.
Key benefits
- Compact technical printing designed for dependable day-to-day CAD output
- Supports fast turnaround on drawings, plans and presentation graphics
- Well suited to teams that need accuracy without over-specifying the system
- Up to 90 A1 prints an hour, 25 seconds a sheet
- ±0.1% line accuracy and lines as fine as 0.02 mm
- 50-sheet input tray for A4 and A3, plus manual feed up to A0
Features
- Warranty: One-year limited hardware warranty
- Release Date: Oct/2023
- Paper Capacity: Input tray: 50 sheets
Print Performance
- Print Technology: HP Thermal Inkjet
- Print Speed: 25 sec/page on A1, 90 A1 prints per hour (mechanical, Fast mode)
- Print Resolution: Up to 2400 x 1200 optimized dpi
- Line Accuracy: ±0.1%
- Minimum Line Width: 0.02 mm (via raster driver)
Ink & Colour
- Ink Type: Pigment-based (C, M, Y, mK)
- Ink Cartridge Sizes: 130-ml and 300-ml cartridges
- Printheads: 1 printhead (C, M, Y, mK); 1376 nozzles per colour, 5504 total
Media Handling
- Max Roll/Sheet Size: Roll: 369-914 mm; Manual feed sheet: up to 914 x 1676 mm (A0); Input tray: A4/A3 (210x279 to 305x457 mm)
- Maximum Roll Diameter: 100 mm
- Paper Weight (Grammage): 60 to 280 g/m² (roll/manual feed); 60 to 220 g/m² (input tray)
- Media Thickness: Up to 0.3 mm
- Applications: Line drawings; Renderings; Presentations; Maps; Posters
- Media Handling: Sheet feed, roll feed, input tray, media bin, automatic horizontal cutter
Scanning
- Built-in Scanner: No
- Functions: Print only (single-function plotter)
Workflow
- Memory: 1 GB (no hard disk)
- Connectivity: Gigabit Ethernet (1000Base-T), Wi-Fi 802.11b/g/n; HP-GL/2, HP-RTL, TIFF, JPEG, URF, CALS G4
- Print Languages: TIFF, JPEG, URF, HP-GL/2, HP-RTL, CALS G4
Physical
- Dimensions (W x D x H): 1407 x 701 x 967 mm
- Weight: 47 kg
Compare with other models in the range
Frequently asked questions
Can I see it running before I buy?
Talk to us and we'll organise a demonstration on the machine you're considering, at our Demonstration Centre in Woking.
About the Demonstration Centre →
Who installs and looks after it?
We supply, install and support every machine we sell. A Service Plan keeps it running: manufacturer-trained engineers, genuine manufacturer parts and one number to call.
Can I spread the cost?
Most customers spread the cost over 36 or 60 months. We work with a finance provider, or a broker of your choice — speak to us and we will help you find the right option for your business.
Do you pass on manufacturer offers?
Yes. Every cashback and promotional offer on printers is passed from our partners to you.
Where do you work?
We supply and support businesses across London and South England.
